Product details
Looking for more insights and a complete overview? Download the full technical data sheet for further information on this product.
CENTRIFUGAL VERTICAL PUMPS
DVM Series
Centrifugal Vertical pumps SGM Series have an electric motor with direct transmission and cold-box with gas-seal.
APPLICATIONS
- Continuous processes with industrial gases
- Air separation units (ASU)
- Recycling
- Liquid transfer between storage tanks
- Process and back-up operations
Scroll to discover
Features and information
TECHNICAL FEATURES
- Available in single stage or multistage configuration
- Electric motor with direct transmission
- Piloted by variable frequency drive for different speeds and operating points
- Cartridge labyrinth gas seal (single or double type)
- Low sealing gas consumption required
- Purged bearing grease retaining chamber
- Purged warm box
- Composite insulating flange
- Inducer to minimize required NPSH
TRANSFERRED FLUIDS
LIN, LOX, LAR
STANDARD ACCESSORIES
- Labyrinth gas seal control panel
- Differential pressure transmitters for monitoring the seal gas efficiency
- Flow meters for monitoring the gas flow through the pump lantern and seal
- Differential pressure regulator for an accurate gas flow adjustment
- PT100 for monitoring the seal gas leakage and pump cool-down
- Motor front bearing grease retaining chamber
- Expansion line to minimize the required seal gas reference pressure
OPTIONAL ACCESSORIES
- PT100 for monitoring the motor front bearing temperature
- Front motor bearing heating belt
- Suction filter
- Suction and discharge flexible hoses
STANDARDS
Designed according to:
- European Directive Machinery
- EIGA/IGC/CGA guidelines
TEST AND CHECKS
- Dimensional control of each mechanical component before assembly
- Performance test with LIN available for class and customer
